Voxengo Deconvolver

IR Deconvolution Tool

User's Manual: English
Downloaded by 1352 users, 105 countries (recent 90 days)

Recently, sampling (convolution) reverbs have become more and more in demand.  With convolution, we have an opportunity to capture the sound of anything in the world that can generate a reverb and use these sound impulses freely in any situation imaginable.  This enables us to use the sound of high-end reverb units, real-world rooms, halls, cathedrals, synthetic reverbs and other sources, including non-reverb ones, without any hassle and in a uniform way using only a single program or a plug-in module.

Although there are many different sources of impulse responses, we also face the difficulties of acquiring these so they can be used seamlessly in any software environment.

In many cases during some stage of the impulse capture, we typically have a rather large set of recorded test tones that were run through some device or mic'ed in some room.  This poses the difficulty of recovering the impulses conveniently and with minimal user effort.  The other problem we may face is the input or the output bit-depth incompatibility of the recorded and the recovered files.  Some convolution plug-ins tend to support only a small subset of available bit-depths.  And alike, existing deconvolution programs and plug-ins support only the given sample rates and bit depths, and tend to offer a very poor quality deconvolution.

Voxengo Deconvolver overcomes these problems.  First of all, it supports almost all sample formats (bit-depths) of uncompressed mono/stereo WAV files.  Secondly, it offers a very convenient environment in which to deconvolve large sets of recorded files.  Voxengo Deconvolver also offers a true mathematical FFT deconvolution which delivers 100% exact deconvolution.  At the same time, this puts a huge demand on the system memory: deconvolving a 25-second stereo file at 96 kHz may require up to 100 MB of memory.

Features

  • True FFT deconvolution
  • Reversed test tone deconvolution technique
  • Minimum-phase transform option
  • Reads 8, 16, 24, 32, 64 bit PCM and IEEE WAV files
  • Writes 8, 16, 24 PCM and 32 IEEE WAV files
  • Multi-channel file support
  • Batch support
  • Built-in DC removal filter
  • Built-in test tone generator
  • Automatic stereo normalization
  • Inverted impulse response creation
  • 64-bit processing
  • All sample rates supported

Requirements

  • Windows XP or any later 32-bit Windows OS
  • About 370 kB of harddisk space
  • For best performance a fast processor is required

Demo Limitations

Unregistered demo version does not allows batch processing and is limited to 3 deconvolutions per program's session only.

More Information

www.noisevault.com is a vast source for convolutional reverb info and impulses.

What's New

Version 1.9.3, 03-oct-2007

  • "Reversed technique" problem fixed.
  • Optional low- and high-pass filtering implemented.
  • Test tone generator file naming problem fixed (previously a default generated name was used even if another name was supplied in the file saving dialog).

Version 1.9, 25-jul-2005

  • Complete rewrite of the application.
  • Multi-channel support implemented.
  • Now, by default Deconvolver creates new file appending the "dc" suffix.
  • Problems with the "reversed technique" fixed.

Version 1.8, 14-oct-2004

Automatic normalization disable switch added.

Version 1.7, 20-apr-2004

  • Now reversed test tone deconvolution should work with sample rates above 44.1kHz, too.
  • Now test tone generator can generate test tone both with and without fade-in and fade-out.

Version 1.6, 29-feb-2004

  • Reversed test tone deconvolution technique implemented.
  • Inversed impulse response creation implemented.
  • Test tone generator improved.  Now test tones incorporate both short fade-in and fade-out.

Version 1.5, 23-jul-2003

  • Minimum-phase transform option added.
  • Test tone generator added.

Version 1.4, 29-may-2003

Initial release.
